Solenoid valve 22FDA-F5T-W230R-20/LBO Chhabra power
Date:2025/3/13 8:19:22 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,Solenoid valve 22FDA-F5T-W230R-20/LBO is a high-performance plug-in solenoid reversing valve, which is widely used in hydraulic control systems. It can control the movement of the valve core through electromagnetic force, thereby realizing multiple functions such as on-off, pressure maintenance and unloading of the fluid medium. The solenoid valve has the advantages of compact structure, large flow, small pressure loss, and fast switching speed. It is suitable for hydraulic systems that require high precision and fast response.
Performance characteristics
1. On-off control: Control the opening or closing of the valve by electromagnetic force to realize the on-off control of liquid or gas.
2. Pressure maintenance function: Keep the pressure in the system stable under specific working conditions to ensure the safety of system operation.
3. Unloading function: When the pressure needs to be reduced or released, the pressure is unloaded to the specified circuit or environment by controlling the opening of the valve.
4. Fast response: It has a fast switching response time and can quickly open or close the fluid channel.
5. Automation control: It can be used in conjunction with the automation system and remotely controlled by electrical signals to realize automated fluid control.
6. High reliability: electromagnetic force control is adopted, the structure is simple and reliable, and the service life is long.
Application
- Power plant: Test solenoid valve used in lubricating oil station of small steam turbine in power plant, controls the opening and closing of test oil circuit, and realizes accurate detection and maintenance of lubricating oil system.
- Industrial hydraulic system: In various industrial hydraulic equipment, such as machine tools, injection molding machines, die-casting machines, etc., it is used to control the on-off and flow direction of hydraulic oil to realize automatic operation of equipment.
- Metallurgy, chemical industry, petroleum and other industries: In occasions where fluid medium needs to be precisely controlled, such as continuous casting machine in metallurgical industry, reactor in chemical industry, drilling platform in petroleum industry, etc., ensure the stability and safety of production process.
Installation and maintenance
1. Installation points: When installing the solenoid valve, it is necessary to ensure that the flow direction of the solenoid valve is consistent with the flow direction marked in the pipeline to avoid reverse flow caused by installation errors. At the same time, it is necessary to ensure the sealing of the connection between the solenoid valve and the pipeline to prevent medium leakage.
2. Maintenance suggestions: Regularly check the sealing performance and operating flexibility of the solenoid valve to detect and deal with potential problems in time. During maintenance, pay attention to the protection of key components such as solenoid valves to avoid damage caused by improper operation.
