China Manufacturer bimetallic actuated thermometers WTY-1021

Date:2023/5/10 10:14:42 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

China Manufacturer bimetallic actuated thermometers WTY-1021



DESCRIPTION



The WTY-1021 thermometer, also known as remote bimetallic thermometer, can meet the needs of on-site temperature measurement and long-distance transmission. Remote bimetallic thermometers can directly measure the temperature of liquid, steam, gas media, and solid surfaces in various production processes.



The thermometer WTY-1021 has the characteristics of small temperature probe, high sensitivity, linear scale, and long service life. At the same time, it can also achieve multiple functions such as remote output resistance signal (PT100), seismic resistance, corrosion resistance, and high-power switching signal. Convenient installation, widely used in temperature measurement environments in the industrial industry.



TECHNICAL PARAMETER OF THERMOMETER WTY-1021



1. Temperature measurement range: -40~600 ℃

2. Environmental temperature: -10~55 ℃

3. Relative humidity: ≤ 95%

4. Accuracy level: 1.5

5. Time constant: ≤ 60S

6. Probe pressure resistance: ≤ 6Mpa

7. Probe diameter: φ 8-10mm, movable external thread: M27 * 2

8. Output: Thermal resistance PT100 (single or dual output) or 4-20mA current

9. Protection level: IP55



REGULAR MODELS



DET50A	DET100A	DET150A
DET200A	DET250A	DET300A
TDZ-1	TDZ-1E-03	3000TD
4000TD	HTD-50-6	HTD-250-6
HL-6-300-15	HL-3-200-15	HTD-150-3
TDZ-1E-03	TDZ-1G	TDZ-1-H





PRODUCT PICTURE
