Insulating Adhesives and Varnish for generator

Date:2016/7/13 9:48:57 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

China Manufacturer Insulating Adhesives and Varnish for Generator





RT curing HR anti-corona varnish
Application: anti-corona processing for stator winding end of high voltage generator.



J0704 RT curing Injection Adhesive
Application: injection and adhesion of dacron sheath glass fiber for stator’s winding end hoop and interlayer hoop.



J0705 RT curing silicon steel sheet adhesive
Application: J0705 is used for adhesion of the stator core silicon steel sheets of large high-voltage generators during lamination process, also for avoid silicon steel sheets loosen by coating on the stator core’s end to bond all the sheets as a whole.



J0708 RT curing epoxy adhesive
Application: insulation for the joint of stator winding bar and ground insulation of the connecting lines by coating the interlayers of mica tapes.



J0709 RT curing dacron glass fibre coating adhesive
Application: surface coating for dacron sheath glass fiber ropes for stator’s winding end hoop.



J0801 RT curing thermal conductive perfusion adhesive
Application: applies to iron wall generators, for gaps perfusion between silicon steel sheets and the base wall after the stator core is laminated.



J0912 RT curing thermal conductivity perfusion adhesive for insulation box
Application: perfusion of joint insulation box of the stator winding bar end.
J0912 is thermal conductive and elastic.
Insulating Adhesives and Varnish




841 RT curing epoxy adhesive
Application: insulation for the joint of stator winding bar and ground insulation of the connecting lines by coating the interlayers of mica tapes.
Insulating Adhesives and Varnish



792 RT curing epoxy dipping adhesive
Application: surface coating and insulating processing for tying ropes and ties of the stator winding end of large generators.
Insulating Adhesives and Varnish


793 RT curing epoxy dipping adhesive
Application: dipping of tying ropes and ties of the stator winding end of large generators, and dipping of conformal dacron felt.
Insulating Adhesives and Varnish


944 epoxy casting varnish
Application: surface insulation painting for generator stator winding end, also for clearing gaps, fastening the stator winding end, and strengthening moisture proof and dustproof.



H31-3 epoxy-ester insulating varnish
Application: surface coating and sealing for generator winding and electric appliances winding, and surface insulation coating of other electric components.



EP5 iron red modified epoxy coating varnish
Application: surface coating for stator winding (coil) end of high voltage generator, and surface insulation coating for rotor’s magnetic pole.



J0301 RT curing semiconductor filler
Application: used for the fixation inside the stator winding bar slot of hydro generator, can fill in the gaps effectively and lower the slot potential.



J0403 F-class stator core adhesive
Application: adhesion of bonding sheets of stator core in the factory.



FJ6189 F-class epoxy glass cloth
Application: interturn insulation for convex type pole coil of hydro generators rotor, and thermo-compression formation of pole layer plate.



FJ1840 F-class epoxy modified dipping adhesive
Application: used for dipping the interturn insulating glass cloth of salient type pole coil of hydro generators rotor. When coil and plate needs to be bonded, the conformal felt between the coil and plate can be dipped with FJ1840, then be pressed and heated to bond the coil and plate.



53841YQ RT curing adhesive
Application: 53841YQ is room temperature curing two-component adhesive, uses low viscosity epoxy resin and liquid amine as main ingredients. This product has high mechanical strength, good electrical strength, F-class heat resistance. It applies to the painting and adhesion of stators and rotors in turbines, generators and exciters, also applies to the painting and adhesion of AC and DC generators insulation.



56102 RT curing epoxy adhesive
Application: 56102 is room temperature curing two-component adhesive, uses low viscosity epoxy resin and liquid amine as main ingredients. It is equivalent to the 53841YQ of Westinghouse Corporation. This product has high mechanical strength, high heat deformation temperature and heat resistance. It does not contain active diluents, not stimulate to the skin. 56102 is suitable for the painting and adhesion of stators and rotors in turbines, generators and exciters, also applies to the painting and adhesion of AC and DC generators insulation.



HDJ-102 RT curing epoxy adhesive
Application: HDJ-102 is room temperature curing two-component adhesive, uses low viscosity epoxy resin and liquid amine as main ingredients. It is equivalent to the 53841YQ of Westinghouse Corporation. This product has high mechanical strength, high heat deformation temperature and heat resistance. It does not contain active diluents, not stimulate to the skin. HDJ-102 is suitable for the painting and adhesion of stators and rotors in turbines, generators and exciters, also applies to the painting and adhesion of AC and DC generators insulation.



HDJ-138 dipping adhesive
Application: HDJ-138 is room temperature curing two-component adhesive, uses low viscosity epoxy resin and liquid amine as main ingredients, and solvent as toluene. This product has high mechanical strength, high heat deformation temperature and heat resistance. HDJ-138 is suitable for the painting and dipping of stators and rotors in turbines, generators and exciters, also applies to the painting and dipping of AC and DC generators insulation.
