The flame detector probe 2653-093-03 is a specialized probe for boiler furnace flame detection, which can continuously monitor the presence and combustion status of flames. Once abnormalities are detected (such as extinguishing), protective measures are triggered in a timely manner to prevent safety accidents. It has strong anti-interference characteristics and is mainly used to identify the combustion status of flames and ensure the safe operation of boilers.

Installation and daily maintenance precautions for flame detector probe 2653-093-03:

1. Accurate positioning:

During installation, it is necessary to ensure that the probe is facing the core area of the flame (or the root of the flame) and avoiding reflected light or obstructions on the inner wall of the boiler to ensure the accuracy of signal acquisition.

2. Regular cleaning:

Boiler rooms usually have a lot of oil and dust, so it is necessary to regularly use anhydrous alcohol and soft bristled brushes to wipe the transparent parts of the probe (such as the lens and sensing window) to prevent missed detection due to a decrease in light transmittance.

3. Environmental protection:

The working temperature of the probe is usually strictly limited (generally not exceeding 85 ℃). When installing in high-temperature areas, it is necessary to install insulation baffles or heat sinks; At the same time, shielded wires should be used for signal lines and kept away from strong electromagnetic interference sources such as frequency converters to prevent false alarms.

Due to the installation of flame detector probe 2653-093-03 in harsh environments such as boilers with high temperature and high dust, correct installation and maintenance are crucial for its lifespan and detection accuracy.
