The coupling elastic block LDY60-30*480*17 is an important vulnerable component to ensure the smooth operation of the LDY type vertical multi-stage centrifugal oil pump. With its excellent physical properties and precise structural adaptation, it achieves smooth power transmission and effective isolation of vibration under various harsh working conditions, ensuring that the lubricating oil system of large key equipment such as steam turbines and oxygen concentrators can continuously, stably, and safely supply oil. It is an indispensable flexible connection link in industrial fluid systems.



Considering the characteristic of LDY oil pump conveying medium being turbine oil, this elastic block is usually made of high-quality high-performance rubber or polyurethane material. These materials not only have excellent elasticity and resilience, but also have good oil resistance and wear resistance, and can work normally in contact with lubricating oil or oil rich environments for a long time without aging, hardening, or cracking. Its structural dimensions are precisely customized according to LDY60-30 * 480 * 17, ensuring a perfect fit with the coupling half body, ensuring the tightness of the transmission and facilitating quick replacement during maintenance.
