globe valve HY-SHV16.02Z Mundra Ultra Mega power
Date:2025/3/21 14:22:00 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,Globe valve HY-SHV16.02Z is a right-angle stop valve with a flat sealing structure. It is suitable for opening and closing and flow regulation of medium and low pressure and conventional medium pipelines.
Application areas:
Mainly suitable for EH oil control systems. The high-pressure oil supplied to the actuator flows to the servo valve through the stop valve to operate the oil motor.
Functional features:
When the stop valve is closed, the high-pressure oil circuit is cut off, so that the actuator stops when the turbine is running, so that the filter and servo valve can be replaced. Its working principle is similar to that of the stop valve. It can control the full opening and closing of the oil circuit, and can also throttle by adjusting the opening of the cone valve.
Structural composition:
It is mainly composed of valve stem, body, valve seat, gasket, sealing ring, cone core, cap, etc.
