The CJZ-B4G Wall-mounted smart display Vibration monitor, control and display instrument is an intelligent instrument. It can be used with the SZ-6 series magnetoelectric speed sensor to continuously monitor and measure the amplitude and intensity of bearing vibration of various rotating machinery.

Technical parameters of CJZ-B4G vibration monitoring and control display instrument:

Input signal: SZ series magnetoelectric speed sensor;

Frequency response range: vibration meter 15~200Hz; intensity meter 10~100Hz;

Display mode: 3-digit LED digital display, accuracy: ±1.0%;

Measurement range: 0~500μm (peak-to-peak amplitude); 0~30.0mm/s (vibration intensity);

Current output: corresponding range linear output 4~20 mA;

Accuracy: ±1.0% of full scale; Load: 500Ω;

Alarm setting: 2 points per channel upper limit, and can be set arbitrarily within the full range;

Alarm output: LED indicator, relay switch output, capacity AC250V/2A, DC28V/2A;

Power supply: 220V AC±10%, 50Hz; Power consumption <10W;

Use environment: temperature 0~50℃; storage temperature -40~60℃; relative humidity 20～90% (non-condensing);
