CZJ-4D vibration module Monitor is an indispensable monitoring and protection device for various rotating mechanical devices such as fans, compressors, and steam turbine generators. It can be used in conjunction with the SZ series speed sensor to continuously monitor and measure the bearing vibration peak-to-peak value or vibration intensity (effective value of speed) of various rotating machinery. It has a current output proportional to the measured value and can be directly connected to the DCS, PLC system, and paperless recorder. When the vibration exceeds the limit, it can automatically provide an alarm relay switch contact output.

This product has the characteristics of high precision, stable performance, strong anti-interference ability, and high reliability. It can be widely used in power, machinery, chemical, metallurgy and other enterprises, and is suitable for the design of monitoring systems for small and medium-sized rotating mechanical devices.



Technical parameters of CZJ-4D vibration module Monitor:



Input signal: Four SZ series magnetoelectric speed sensor signals can be input simultaneously;



Measurement range: Vibration displacement: (0-500) μm, can be set according to requirements;



Vibration intensity: (0-30.0) mm/s, can be set according to requirements;



Measurement accuracy: ±1.0% of full scale (at 25°C);



Display mode: Three-digit LED digital display, vibration displacement resolution 1, vibration intensity resolution 0.1;



Frequency response range: Vibration displacement: (14-100) Hz; Vibration intensity: (11-100) HZ
